Porsche Panamera Instrument Cluster Wiring Diagram (2015–2016)

This OEM wiring manual details the Instrument Cluster System schematics for Porsche Panamera 2015–2016 models. It includes power supply circuits, CAN/LIN bus communications, gauge input wiring, warning lamp circuits, and display integration. Essential for diagnostic technicians repairing gauge faults, cluster backlight failures, or CAN-based data display errors.

? Manual Coverage:

• Primary Circuits Covered:

  • Instrument cluster power and ground wiring

  • Communication lines for CAN Bus integration

  • LIN Bus lines for submodule controls

  • Backlighting power circuit and dimmer control

  • Gauge signal input circuits (speedometer, tachometer, coolant temp, fuel level)

  • Warning indicator wiring (ABS, ESP, Airbag, TPMS, Check Engine, Oil Pressure)

  • Digital display integration circuit for driver information system

• Connector IDs Identified:

  • Main instrument cluster connector

  • Secondary connector (where equipped for additional features)

  • Gateway or BCM connector related to instrument cluster communication

• Diagnostic Relevance:

  • Fault tracing for gauge inoperability

  • Backlight dimming failures

  • CAN Bus communication errors affecting display data

  • Warning lamp circuit continuity tests
