Navistar Diamond Logic Builder (DLB) Chassis Diagnostic & Programming Software

The Navistar® Diamond Logic™ Builder software provides the ability to program, diagnose and simulate features in the Electrical System Controller or Body Controller (ESC/BC) module on the Industry’s First High-Performance Trucks®. The Diamond Logic™ Builder program allows users to configure switches, the gauge cluster, and the parameters that are programmed in the ESC/BC.

version: 15814

release: 6.2022

Supported languages: English

Diamond Logic Builder features:

• Read Fault and clear diagnostic fault codes
• View vehicle parameters and features
• Bi-directional control of electrical components
• View switch location and cluster configuration
• Automatic module detection
• Graph parameters
• Record snapshots

Diamond Logic Builder Coverage:

• international 4200/4300/4400 Series
• International 7000 Series
• International 8000 Series
• International CF Series (Cluster faults, Test all gauges except fuel, Odometer set)
• International ProStar/LoneStar/WorkStar/TranStar/DuraStar/CityStar

Minimum system requirements:

• AMD or Intel Celeron/Pentium CPU 1.5 GHz or higher,
• 2 GB RAM or higher
• 2 GB free space,
• USB 1.1 port (USB 2.0 recommended)
• Microsoft Windows 7 SP1 or higher
